Avatar HD Nano Kit V3 with 32GB DVR For Avatar HD Video System

filler

Price:
$109

Stock:
Out of stock

Description

The Avatar HD Nano Kit V3 features a 4:3 native sensor, wide voltage input, and higher transmit power.

Features

  • 3.1~13V
  • 500mW
  • FOV160°
  • Metal case
  • 1080P/60fps
  • 4:3 native sensor
  • Built-in 32G storage
  • 18.5g light-weight
  • Nano Camera 14*14mm

Specifications

Camera

  • Model: Avatar HD Nano Camera V3
  • Image Sensor: 1/3.2-Inch 4Mp 4:3 sensor
  • Resolution: 1080P/60fps,720P/120fps,720P/60fps
  • Ratio: 4:3 native / 16:9
  • Lens: 2.1mm
  • FOV: 160°
  • Aperture: F2.0
  • Shutter: Rolling Shutter
  • Min.Illumination: 0.001Lux
  • Weight: 3g (without cable)
  • Dimensions: 14*14*16.8mm
  • Coaxial Cable: 90mm(default)/140mm
VTX
  • Model: Avatar HD Mini VTX V3
  • Communication Frequency: 5.725-5.850GHz
  • Transmitter Power (EIRP) FCC:<27dBm;CE:<14dBm;SRRC:<20dBm;
  • MIC:<25dBm
  • I/O Interface: JST1.0*4(Power in)JST0.8*4(USB)
  • Mounting Holes: 25.5*25.5mm(M2 hole);20*20mm(M3 hole)
  • Dimensions: 31.5*31.5*9.4mm
  • Storage: 32G
  • Recording: 1080p/720p
  • Weight: 13.4g
  • Operating Temperature: -20-40℃
  • Channels: 8
  • Wide Power Input: 3.1V-13V
  • Supported FC System: Betaflight; Inav; Fettec; Kiss; ArduPliot
  • OSD: Canvas mode
  • Latency Average latency: 22ms
  • Antenna: 1(IPEX)
VTX Antenna
  • Model: Avatar V2 antenna
  • Polarization: LHCP
  • Bandwidth: 5600MHz-6000MHz
  • Average Gain: 1.9dBi
  • VSWR: ≤1.5
  • Interface: IPEX-1
  • Line Length: 105mm
  • Dimension: R15*45mm(without cable)
  • Weight: 2g

Includes

  • 1x Avatar HD Nano Kit V3
  • 1x 4 Pin USB Cable
  • 1x 4 Pin Power Cable
  • 2x M2x4/5/6mm Screws
  • 4x M2x14mm Screws
  • 4x M2*5*0.5mm washer
  • 5x 2.1x3.4x1mm Gasket
  • 1x 14 to19mm bracket

Walksnail Avatar HD Nano Kit V3 Product Features

Bullet Point for Walksnail Avatar HD Nano Kit V3

  • The Walksnail Avatar HD Nano Kit V3 supports 1080P/60fps, with a 4:3 native sensor that provides smooth and stunning images. With this kit, you can capture flying footage with exceptional clarity and detail.

The Walksnail Avatar HD Nano Kit V3 supports 1080P/60fps, with a 4:3 native sensor

  • Walksnail Avatar HD Nano Kit V3 is suitable for more drones, with 3.1-13V voltage input and 500mw power output, you'll be able to fly various kinds of drones with amazing video quality and range.
with 3.1-13V voltage input and 500mw power output
  • Nano camera V3 with dimensions of 14*14cm and a weight of only 3g, equipped with a 2.1mm lens and 160° FOV, provides clearer and more realistic image quality.

  • The Avatar vtx comes with 32g built-in storage, it can record 1080p HD and interference-free flight footages without adding an extra SD card and an action camera, reducing the overall weight of the drones and extending the flight time, allowing you to experience a more comfortable flight while recording 1080 HD videos.
32g built-in storage
  • Canvas Mode:supporting Betaflight, kiss, Inav, Ardu full OSD display and customization, you'll be able to customize various OSD fonts, colors and patterns you like and easily adjust the parameters you want via remote control.
Canvas Mode

Walksnail Avatar HD Nano Kit V3 Dimensions
Walksnail Avatar HD Mini VTX V3 wiring diagram
Q: Can I use analog channels?/Can I fly with other analog pilots?
A: Yes, when you upgrade the firmware to 34.40.15 version, need switch to racing mode.

FPV Regulatory Notice ⚠

Customer Reviews

Based on 3 reviews
100%
(3)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
f
franklin reaves
avatar hd nano kit v3

Very high quality

D
Demetrios Cherpelis
Walksnail review by Kanenas-FPV

Walksnail is about to dominate the FPV seen if they continue to create and keep prices low. We are the beta testers for this entire market.

J
Jeffrey Bright
Compared to analog, it is 100% better

It is like needing glasses your entire life and seeing through those long needed glasses for the first time! It is absolutely amazing! I even managed to make a 5" quad under 250 grams with this V3! Range is more than I fly.
