Description
Experience FPV like never before with the Fat Shark HDO+ Goggles, featuring an enhanced OSD menu that simplifies goggle adjustments. This latest model is packed with customizable options to deliver a tailored experience for every pilot. The HDO+ offers an expanded field of view and high-resolution OLED displays for breathtaking clarity. Its upgraded optical engine allows for precise focus and interpapillary distance (IPD) adjustments, ensuring exceptional comfort and visual precision. The Fat Shark HDO+ is designed to keep up with the demands of today’s FPV pilots.
Features
- Upgraded OSD Menu
- Brightness/Contrast Control
- Coarse Focus Adjustment
- Head Strap and Face Fit
- AV Connector Pin-Out
- Low-Battery Warning
- RX Power Switch
- DVR Operation
- Channel Select
- Compatibility
- Versatility
- Playback
Specifications
- Optics
- IPD (interpupillary distance): 57 to 70 mm (adjustable)
- FOV (Field of View): 50 degrees diagonal
- Focus: +2 to -6 diopters (adjustable)
- Display
- OLED Displays: Two seeya 0.49”
- DIGITAL VIDEO IN Mode: 16:9
- Auto-Selecting: NTSC/PAL
- Resolution: 1920 x 1080
- AV Mode: 16:9
- AV Mode: 4:3
-
User Controls
- Display Control (Brightness and Contrast)
- Power Button / Fan Control
- Channel Selection
- Volume Control
- Mode Selection
- DVR Control
-
Interface
- 3.5mm 3p earphone port
- 3.5mm AV in/out port
- Power input port
- RF Module Bay
- Power Button
- MicroSD
- Electrical
- Analog DVR: MicroSD support to 32 GB, Upgradeable via SD card
- Record Rate: 6 Mbps (MJPG compression, 30 fps, AVI)
- Power Supply: 7 – 25V input voltage (2S – 6S Supply)
- File playback: Native recording, no codec support
- Mechanical
- Headset: Ergonomic molded headset with adjustable headband
- Dimensions: 169.2 x 80 x 45.5 mm
- Weight: 235.8 g
- Audio: Stereo
Includes
- 1x Fat Shark HDO+ FPV Goggles
- 1x Lens Cleaning Cloth
- 1x Carrying Case
- 1x XT60 to barrel connector power cable
