F7 HD+F55A PROII 3-6S 30x30 Stack with F7 FC and 32Bit 55A ESC Solder-Free

Roll over image to zoom in

F7 HD+F55A PROII 3-6S 30x30 Stack with F7 FC and 32Bit 55A ESC Solder-Free

Name: F7 HD+F55A PROII 3-6S 30x30 Stack with F7 FC and 32Bit 55A ESC Solder-Free
Brand: T-Motor
SKU: 313646980833
Price: 159.99 USD
Availability: InStock

T-Motor

filler

Share this product

*Now shipping with the NEW T-Motor F7 (BMI270 Gyro) HD flight controller*

Solder Free: Everything is 100% plug-n-play, the MR30 Quick Connection System makes assembly a breeze and removes the need for any soldering!

Compatible Rotor Riot Fames:

- Le Drib Skyeliner MK3 Frame
- Let's Fly RC TANQ
- Vannystyle 5" Frame
- Le Drib Skyeliner HD Frame
- HD1-VS Frame
- Bubby FPV Moxy Frame

NOTE: If you plan to use this stack with a different frame you must make sure that the distance between the stack screw and prop nut are no longer than 90mm. (See Image)

FC Specifications

Input Voltage: 12-25.2V
MCU: STM32F722RET6
IMU: BMI270
OSD: Yes
Blackbox: 16MB Onboard Flash
Uarts: 6
ESC Connections: 6
Firmware: Betaflight
Target: TMOTOR F7
BEC: 5V 2A /10V 2A
LC Filter: Yes
Current Sensor: Esc Telemetry / Current ADC
Buzzer: Pads
Barometer: No
Dimensions: 37x37x7mm
Mounting Pattern: 30.5x30.5mm
Weight: 7g

ESC SPECIFICATIONS

Continuous current: 4*55A
BLHeli_32 32bit
Burst current: 4*75A
BEC Output: 10V @2.0A
Size: 45x41x7.3mm
Weight: 17.3g (Including Heatsink)
Support DSHOT150/300/600/1200
Four soldered MR30 female connectors with 77mm long #20 silicone wires

INCLUDES

1x T-Motor F7 HD Flight Controller
1x T-Motor F55A Pro II 4in1 ESC

Works great!

Very nice Stack. Easy to install, works great out of the box.

Misleading, will not recommend for friends that are starting out

What a bummer of a FC, the only thing “solder-free” about this is the xt60 and capacitor. Literally everything else you have to solder. No plug for the receiver, no plug for gps, and if you try to put it in literally any other frame and still have easy access to the usb-c port the dang DJI plug runs into the xt60 leads. I honestly should’ve paid more attention. If you’re looking for a “solder-free” stack this is not it.

F7 HD+F55A PROII 3-6S 30x30 Stack with F7 FC and 32Bit 55A ESC Solder-Free

Bummer

Flight controller was good but ESC wasn't working for a motor. Hopefully customer support goes well l. Tmotors makes a great product hopefully it was a fluke

Drone is very shaky and program issues with the other

I purchased two of these stacks.For some reason my drone is very shaky for the first couple of minutes of the flight with one of the stacks. The other stack was not programmed properly the motors were set up with the props spinning the wrong direction so I remounted the props to go the other direction now the drone goes about foot off the ground an shuts down. Haven’t had time to reprogram this stack so not sure if it’s bad or not.

Hello Rish,

We only put a very basic tune on the plug and play stacks, as for the issues with the motors it sounds like you skipped doing the Motor Order and Motor Direction wizards after installing the stack on the drone. I have reach out to you directly through our support channel to help resolve the issue.
