TX16S MKII MAX Joshua Bardwell Edition Radio Controller - ELRS
Hurry up, only 2 items left in stock.
RadioMaster has officially teamed up with the acclaimed FPV pilot Joshua Bardwell for this special JB Edition TX16S Radio!
The RadioMaster TX16S Mark II MAX PRO Radio Transmitter is the latest in radio transmitter technology. This radio features Hall V4.0 Gimbals, an ELRS Internal Module, OpenTX and EdgeTX compatibility, and 2.4GHz radio frequency with 16 Channels. This updated design includes an easily removable battery cover, raised and flat grips for better ergonomics, and improved S1/S2 knobs with center detents. The 4.3" IPS color display provides easy programming with touch panel precision and the brand new 3.5mm audio headphone jack and built-in dual speakers provide great audio options for pilots! This JB version comes with a white LED gimbal light mod set!
Features
- Optimized charge IC now allows up to 2.2A internal USB-C charge current.
- New charge circuitry with integrated reverse-polarity protection
- Optional high/low rear grips included for improved ergonomics
- Redesigned battery cover for improved battery access
- Improved internal circuitry and optimized power supply
- Rear mounted audio jack provided headphone output
- Improved S1/S2 knobs with clear center-detents
- Retooled body shell with improved fit and finish
- White LED Gimbal Light Mod Set
- Hall V4.0 Gimbals
- ELRS version
Specifications
- Display: 4.3-inch TFT full-colour touch display with a resolution of 480 * 272
- Upgrade method: Supports USB-C online / SD card offline upgrade
- Antenna gain: 2db (transmit power adjustable)
- Transmitter module: (CC2500 CYRF6936 A7105 NRF2401)
- Option 2: Internal ELRS (SX1280)
- Transmitting power: (protocol dependent)
- Internal ELRS: Max 250mw
- Channels: Up to 16 channels (depending on the receiver)
- Gimbal:
- Option 1: V4.0 Hall sensor with Aluminium facia.
- Module Bay: JR compatible module bay
- Transmission frequency: 2.400GHz-2.480GHz
- Remote control distance:> 2km @ 22dbm
- Module Firmware: ExpressLRS (ELRS)
- Weight: 750g (without battery)
- Working voltage: 6.6-8.4V DC
- Radio firmware: EdgeTX
- Working current: 400mA
- Size: 287x129x184mm
Download the Joshua Bardwell OpenTX/EdgeTX Voicepack here!
Includes
- 1x RadioMaster TX16S MKII MAX Radio Transmitter - Joshua Bardwell Edition - ELRS
- 1x 18650 BatteryTray (Battery Not Included)
- 1x White LED Gimbal Light Mod Set
- 1x Raised Grips (Set of 2)
- 1x Flat Grips (Set of 2)
- 1x TX16S Key Chain
- 1x Screen Protector
- 1x USB-C Cable
