Description
Foxeers's V4 F7 FC has a clean layout with some quality components. No more worrying about lifting pads during crashes, this FC has through holes for every solder point.
This is a replacement Flight Controller for The Moxy Pro-Spec Built & Tuned.
Pairs best with the Foxeer Reaper 128K 65A ESC.
This is a replacement Flight Controller for The Moxy Pro-Spec Built & Tuned.
Pairs best with the Foxeer Reaper 128K 65A ESC.
Specifications
- Model: F722 V4
- CPU: STM32F722RET6
- Gyro: ICM-42688
- Power Supply: 3~6S Lipo (11V~30V)
- BEC Output: DC5V/3A; DC9V/3A
- OSD: BF OSD
- Black Box: 16M Flash Memory
- UART: 6 Set
- ESC Telemetry: RX4
- Buzzer: YES
- Smart Audio: YES
- LED: 1 Set 2812 LED
- USB: Type-C
- X8: Supported Need CLI
- Firmware: FOXEERF722V4
- Size: 37X37mm
- Mounting Hole: 30.5X30.5mm,Φ4mm
- Weight: 8g
- Working Temperature: -20℃ ~ +55℃
- Working Humidity: 20～95%
- Storage Temperature: -20℃ ~ +70℃
Includes
- 1x Foxeer F722 V4 Flight Controller
- 4x Silicone Grommets
