Description
Features
- 1080P 120fps compatibility
- Sony Starvis Ⅱ Technology
- Built-in 32GB storage
- High frame starlight
- Lightweight design
- 22ms low latency
- Ranging Mode
- Gyroflow Support
- 4km range
- 6V-25.2V
- FOV 160°
Specifications
HD PRO CAMERA
- Resolution: 1080P/60fps;720P/120fps,720P/60fps;1080P/120fps compatibility;
- Image Sensor: 1/1.8-Inch Sony Starvis Ⅱ Sensor
- Model: Avatar HD Pro camera
- Min.Illumination: 0.00001Lux
- Dimensions: 19*19*24mm
- Shutter: Rolling shutter
- Coaxial Cable: 140mm
- Ratio: 16/9; 4/3
- Aperture: F1.6
- Weight: 9.5g
- Lens: 8Mp
- FOV: 160°
AVATAR V2 VTX
- Transmitter Power (EIRP: FCC:<30dBm;CE:<14dBm;SRRC:<20dBm; MIC:<25dBm
- Supported FC System: Betaflight; Inav; Fettec; ArduPilot;Kiss
- 1/O Interface: JST1.0*4(Power in)JST0.8*6(USB)
- Communication Frequency: 5.725-5.850GHz
- Mounting Holes: 25.5*25.5mm; 20*20mm
- Operating Temperature: -20-40℃
- Dimensions: 33.5*33.5*10.5mm
- Latency: Average delay 22ms
- Wide Power Input: 6V-25.2V
- Model: Avatar V2 module
- Recording: 1080p/720p
- OSD: Canvas mode
- Antenna: 1(IPEX)
- Storage: 32G
- Weight: 17.6g
- Channels: 8
AVATAR V2 ANTENNA
- Frequency range: 5600MHz-6000MHz
- Size: R15 X 45mm(without cable)
- Input Impedance: 50Ω
- Polarization: LHCP
- Interface: IPEX-1
- Gain: 1.9dBi
- VSWR: ≤1.5
- Weight: 2g
Includes
- 1x Walksnail Avatar V2 VTX - 32GB w/ Gyro
- 1x Walksnail Avatar HD Pro Camera
- 1x Walksnail Avatar V2 Antenna
- 1x USB transfer extension cable
- 4x M2*5*0.5mm gasket
- 1x 4 Pin silicone cable
- 4x M2*14mm screws
- 8x M2*4mm screws
- 4x M2*5mm screws
- 4x M2*6mm screws
FPV Regulatory Notice ⚠
Customer Reviews
I’ve moved over to Avatar and haven’t looked back. I will admit the O3 picture is better in the daytime, but not once it starts to get dark. The night performance on this vtx is the best out right now. Thumbs up to Walksnail for releasing lenses for these cameras, which is another thing to consider when you’re comparing this to an O3.
Love it !!after a few flights I’m liking it more and more!!!
What a setup!
Works amazing at night time! Also will fit in smaller frames with a little finesse.
I absolutely love the Avatar HD Pro Kit for flying sub 250 drones and especially in low lit areas during the evening hours.
i crashed my skyliner mk3 and needed a new vtx, after some initial confusion regarding a cable needing changed, and updating the software. i found that the avatar v2 pro is an upgrade for the same price. pairs with the fatshark dominator goggles, and the updates are available on rotorriot's website.
